Description
SV rotary vane vacuum pumps are characterized by high pumping speeds even in low pressure ranges and therefore rapid evacuation times.The specially designed exhaust filters provide excellent oil separation.
Maintenance can easily be carried out by the operator.Apart from changing oil and filters at regular service intervals,no further maintenance is required.
SV rotary vane vacuum pumps stand for advanced and energy-efficient vacuum generation in a wide variety of applications in industry throughout the world.
Typical Applications
- Automotive industry
- Food industry
- Heat treatment
- Vacuum coating
- Metallurgy
- Power engineering
- Space simulation
- Medical technology
- Composites and resin degassing
- Vacuum drying
- Leak testing
- Central vacuum systems
Features
Reliable
robust construction, reliable operation, highly resilient carbon fibre vanes, proven performance, over 3 million pumps in operation
High Performance
high pumping speed and low ultimate pressure, designed for continuous operation
Flexible
application-oriented, various design options available, easy adaption to individual customer requirements and processes
Low Operating Costs
energy-efficient, optimum cost-benefit ratio
Easy Servicing
easy service routine
Specifications :
| Model | Pump capacity (m3/h) |
Ultimate vacuum (mbar) |
Motor Power (KW) |
Inlet Diam (inch) | Rotary speed (rpm) |
Oil Capacity | G.W | Noise | Dimensions | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50HZ | 60HZ | 50HZ | 60HZ | 50HZ | 60HZ | (L) | (kg) | dB (A) | (mm) | |||
| SV-630 | 630 | 750 | 0.1～0.5 | 15 | 18.5 | Rp3″ | 1000 | 1200 | 25 | 550 | 80 | 1780*880*730 |
SV630 Overall Dimensions( Unit: Mm)
